10 tonnes Yoke 8-057-10T Weld-On Point with Spring
XLINK WELD-ON PNT 8-057-10T
YOKE WELD-ON POINT WITH SPRING
SKU
71WOP-Y10S
Weight
6.3 lb
Price
$93.81
Mfg. Part #
8-057-10T
Tech Specs
Yoke 10 tonnes 8-057-10T Weld-On Point with Spring
•Pivots through 180°.
•Manufactured from forged alloy steel, quenched and tempered.
•Manufactured and tested in accordance with EN1677-1.
•Load rated parts are 100% magnaflux crack detected.
•Individual forged parts are traceable to Test Certification.
•Proof tested to 2.5 times the WLL.
•Fatigue rated to 1.5 times the WLL.
•All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
•WLL forged onto each product for quick and easy identification.
•Lugs designed to assist the welding process.
•A protected spring keeps the load ring in a required position. The parts are connected in such a way that they remain captive. The spring also reduces noise caused by vibrations
| 3D file download | Item No. |
Working Load Limit lbs.* |
Dimensions (inch) | N.W. lbs. | ||||||||||||
| A | B | C | D | E | F | G | H | L | W | HV | a | |||||
 |
8-057-10T | 22,000 | 5.75 | 2.68 | 3.23 | 0.79 | 1.18 | 4.92 | 1.85 | 3.07 | 7.52 | 2.76 | 0.39 | 0.16 | 6.2 | |
Country of Origin
Made in Taiwan
