8 tonnes Yoke 8-057-8T Weld-On Point with Spring

8 tonnes Yoke 8-057-8T Weld-On Point with Spring
XLINK WELD-ON PNT 8-057-8T
YOKE WELD-ON POINT WITH SPRING
SKU
71WOP-Y08S
Weight
5.8 lb
Price
$67.98
Mfg. Part #
71WOP-Y08S

Tech Specs

Yoke 8 tonnes 8-057-8T Weld-On Point with Spring

•Pivots through 180°.
•Manufactured from forged alloy steel, quenched and tempered.
•Manufactured and tested in accordance with EN1677-1.
•Load rated parts are 100% magnaflux crack detected.
•Individual forged parts are traceable to Test Certification.
•Proof tested to 2.5 times the WLL.
•Fatigue rated to 1.5 times the WLL.
•All YOKE Lifting points meet or exceed all the requirements of ASME B30.26.
•WLL forged onto each product for quick and easy identification.
•Lugs designed to assist the welding process.
•A protected spring keeps the load ring in a required position. The parts are connected in such a way that they remain captive. The spring also reduces noise caused by vibrations

3D file download Item No. Working

Load Limit lbs.*
Dimensions (inch) N.W. lbs.
A B C D E F G H L W HV a
   8-057-8T 17,600 4.76 2.68 2.68 1.02 1.02 4.80 1.85 2.95 6.65 2.17 0.39 0.16 5.7



Country of Origin

Made in Taiwan
