PCA-1270 Open Face Corner Block 4 inch
OPEN FACE CORNER BLOCK
FOR USE WITH WEB SLING
SKU
44WIN-PCA1270
Weight
5.64 lb
Price
$100.00
Brand
Mfg. Part #
PCA1270
Category
Tech Specs
PCA-1270 Open Face Corner Block
4 inch Diameter
Description
The open-face pulley is designed to pull trees perpendicular to a path when the traction comes from a vehicle. It is also useful for deviating trajectory and get around obstacles. In addition, when installed at height, it creates a pulling angle that allows the tip of the log to be slightly lifted and thus reduces friction on the ground.
Made of steel, it is shock-resistant and is generally used paired with the automatic release (PCA-1291). The sheave is smooth and without sharp edges: it will not damage synthetic lines.
Its 100 mm diameter provides excellent efficiency.
Attach it to a tree with one of our polyester slings.
This product is of great interest for you? Check out our Skidding Cone (PCA-1290) which includes this pulley, the automatic release and more!
Specifications
Minimum Breaking Strength (imperial) : N/A
Working Load Limit (imperial) : 20 kN (4496 lbs.)
Certification : ---
Material : Steel
Weight & Dimensions
Weight (imperial) : 5.64 lbs.
Diameter (imperial) : 4 inches
Length (imperial) : 10.63 inches
Width (imperial) : 5.51 inches
Height (imperial) : 5.51 inches
Rope
Minimum diameter (imperial) : 1/4 inches
Maximum diameter (imperial) : 1/2 inches
Additional Information
Not designed for steel cable.
Use it in combination with our automatic release (PCA-1291).
Country of Origin
Made in Canada
